* ACU Variant Coding Cannot Be Completed

ACU Variant Coding was performed, but the controller does not appear to have completed the process successfully.
Check the C176200 DTC status information to identify the specific cause of the coding failure.

If the Information Code is displayed as Unknown Coding and the Part Number is 95910-CV350, perform Variant Coding using CV90. This is the same issue described in https://gims.gitauto.com:8080/jira/browse/GDSN-14897.

If a different Information Code is displayed, the corresponding component must be inspected before Variant Coding can be completed successfully. Please provide the displayed Information Code for further guidance.
