KDS 2.0 - X1 EV Does Not Proceed on the High-Voltage Component Insulation Resistance Test Screen

1. Symptom

After entering the high-voltage component insulation resistance test for the applicable vehicle, the screen does not respond when attempting to proceed from the measurement time input screen to the next screen.

2. Corrective Actions

 - Disconnect the auxiliary battery.

 - Turn the ignition key OFF, turn IG On again, and then proceed with the hood open.

 - Use the SW Update function.
