* ACU Variant Coding Cannot Be Completed

ACU Variant Coding was performed normally, but the controller did not complete the process successfully.
Check the C176200 DTC status information to identify the specific cause of the coding failure.

If the Information Code is displayed as Unknown Coding and the Part Number is 95910-CV350, perform Variant Coding using CV90. This is the same issue described in https://gims.gitauto.com:8080/jira/browse/GDSN-14897.

If a different Information Code is displayed, inspect the corresponding component before attempting Variant Coding again. When requesting support, provide the relevant Information Code.
